Commercial Buildings EN733 DIN24255 Standard End Bare Pump 8inch 6inch Shaft Submersible Suction Pump

1 Set
MOQ
Commercial Buildings EN733 DIN24255 Standard End Bare Pump 8inch 6inch Shaft Submersible Suction Pump
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty: 12 Months
Customized Support: OEM
Model Number: XA150/40
Application: Commercial Buildings, Drinking Water Treatment, Irrigation And Agriculture, Marine, Raw Water Intake, Water Distribution
Horsepower: 50HP To 120HP
Power Source: Electric
Pressure: 1.0 Mpa
Structure: Single-stage Pump
Cable Length: N/M
Outlet Size: DN150
Voltage: 380/400/415V
Power: 37KW To 900KW
Standard: EN733/ DIN24255
Flange: DN200 X DN150
Capacity: 180 To 460m3/h
Head: 24 To 54m
Speed: 1450/1750rpm
Certification: Ce
Basic Infomation
Certification: ce
Model Number: XA150/40
Payment & Shipping Terms
Packaging Details: Plywood case
Supply Ability: 500 Set/Sets per Month
Product Description
Related Products
Non-clogging submersible pump Axially Split Casing Centrifugal Pump Easy maintenance pump
XAZ Monoblock close coupled end suction pump SBS200-670 split case pump XA EN733 DIN24255 standard end suction pump





XA Type Horizontal End Suction Centrifugal Pump

Product Description

XA pumps are used for pumping clean water or liquids which chemical and physical property is similar to water.  For the pumps in same model, the performance can be changed by cutting the outer diameter of impeller(which indicated as the latter A, B or C at the end of the model name).  XA pump is simple in structure, reliable in performance, small in size, light in weight, high lift in suction, low consumption in power and easy in maintenance. For all 60 models, it only have shaft in 4 sizes, bracket in 5 types. For the same model, the shafts, shaft sleeves, shaft seals, bearings and the fasteners of impeller can be interchangeable.
